Epson SureColor SC-P10000 SC-P20000 Printhead FA23001 FA23011 FA23012 PrecisionCore MicroTFP

Product Overview

The Epson PrecisionCore MicroTFP Printhead (Part Numbers FA23001 / FA23011 / FA23012 / ID807V-ASP) is an original, state-of-the-art replacement component designed for 44-inch and 64-inch high-volume production printers. Built with Epson's advanced 2.64-inch PrecisionCore MicroTFP linehead array technology, this printhead features 10 independent color channels with 800 nozzles per channel (8,000 active nozzles total). Delivering variable droplets as small as 3.5 picoliters at firing speeds exceeding 120 million drops per second, it provides maximum print speed, unmatched ink density, and pinpoint placement accuracy for fine art, signage, and photographic output.

Part Information

• Brand: Epson

• Product Type: Inkjet Printhead

• Model: PrecisionCore MicroTFP

• Epson Part Number: FA23001

• Interchangeable / Superseded Part Numbers: FA23011, FA23012, ID807V-ASP

• Technology: PrecisionCore MicroTFP Drop-on-Demand Piezoelectric

• Printhead Width: 2.64 inches

• Nozzle Configuration: 10 Channels x 800 Nozzles (8,000 Active Nozzles Total)

• Minimum Drop Volume: 3.5 pl (Variable Droplet Technology)

• Ink Compatibility: Aqueous Pigment Inks (Epson UltraChrome PRO Ink Systems)

• Condition: Genuine Original

Technical Specifications

Part Number Supersession Information

Part numbers FA23001, FA23011, FA23012, and assembly code ID807V-ASP represent direct factory revisions of the same Epson PrecisionCore MicroTFP printhead. They feature identical mounting geometries, channel architecture, and electrical interfaces, acting as direct drop-in replacements for all compatible SC-P production series printers.

Technical Precision & Operational Advisory

• Aqueous Pigment Compatibility: Formulated exclusively for Epson UltraChrome PRO aqueous pigment ink chemistries. Do not run eco-solvent, UV-curable, or non-approved cleaning solvents through this head assembly, as unapproved chemicals will permanently destroy the MicroTFP piezoelectric elements and internal manifold seals.

• Certified Technician Installation Recommended: PrecisionCore 2.64-inch printhead replacement requires precise physical alignment, head-voltage calibration, rank entry, and electronic purge cycles. Professional installation by a certified service technician is strongly recommended.

• Data Cable Replacement: It is highly recommended to replace flat flexible printhead data cables (FFC) during installation. Contaminated or damaged ribbon cables can cause catastrophic electrical shorts that destroy the printhead and main logic board.

Compatible Printers or Equipment

Important Compatibility Notice

Please verify your existing part number and equipment model before placing an order. If you are unsure about compatibility, please contact us with your printer or machine model and the part number of your existing component.

Packaging and Shipping

The product will be carefully packed to help ensure safe international shipping.

Genuine Product Notice

This product is supplied as a genuine original replacement part.

Warranty and Customer Protection

This product is covered by a 1-year warranty against manufacturing defects, subject to the applicable warranty terms and conditions.

We also provide a 30-day store guarantee for customer protection. If your item arrives damaged, defective, or does not function properly upon receipt, please contact us within 30 days of delivery.

Depending on the situation, we will provide a replacement or a 100% refund of the product payment.

Please contact us before returning any item so we can assist you with the return process.

This warranty and return protection applies in accordance with our applicable warranty and return terms.
